Splayleg in Piglets

by 5m Editor
15 December 2010, at 12:00am

Pig veterinarian, Mark White, describes the causes, prevention and treatment of the various types of splay-leg in a Health Bulletin from NADIS.


Figure 1. Four-legged splay ‘Star’

Figure 2. Hind-limb splay – the most common

Figure 3. Front legs only affected by splaying (PRRS) form

Figure 4. Taping of hocks

Figure 5. Taping of hips

Piglets commonly suffer from a splaying out of the limbs soon after birth, which can severely compromise their ability to suck and to escape from under the sow. The overall incidence of the condition is unknown but can occur:-

  1. as a sporadic outbreak over a short period of time – affecting 20 per cent or more of pigs.
  2. as an occasional condition in isolated pigs or litters.
  3. as a longstanding grumbling problem in a herd. The condition in itself is not fatal – death being due to a combination of starvation and crushing – and as such, the mortality is highly variable, depending on the level and quality of nursing offered to the piglets. Where husbandry and stockmanship is inadequate, mortality can approach 100 per cent of affected piglets.

Presentation

The condition is seen at or soon after birth and can present in a number of forms:-

  1. ‘Stars’ In these pigs, both sets of limbs are splayed out sideways, such that the pig cannot stand and can only get about by crawling or shuffling.

  2. Hind leg splays This is the most common form of the condition. The back legs splay out sideways and forward causing the pig great difficulty in standing on its hind end. Many will ‘dog sit’ and shuffle around on their backsides. This can lead to considerable trauma to the skin and secondary infection.

  3. Front leg splays This is extremely rare – only seen at the height of a PRRS outbreak in the early days of the disease. The hind limbs work normally but the front legs splay out sideways such that the pig moves around with its chin on the floor. Such pigs have great difficulty sucking and mortality levels are high.

Causes

Splayleg is a truly multifactorial condition, although the two least common presentations – front leg splay and ‘stars’ – appear to be usually associated with infection or disease in the dam during late pregnancy, which may affect either nerve or muscle development. Both conditions occur, for example, during acute outbreaks of PRRS.

Hind leg splays – the most common form – however, are less clear cut. In general, the condition is more common:-

  1. in the Landrace breed type
  2. in smaller and weaker piglets
  3. in piglets born onto wet slippery floors (it is uncommon in the outdoor herds)
  4. In association with congenital tremor.

A possible explanation for the development of the condition is that certain piglets may be born with a weakness in their adductor muscles – those which keep the back legs together – as a result of either genetic or developmental weakness – the latter resulting from nutritional, environmental, infectious or managemental insult to the sow, probably in the later stages of pregnancy. Mycotoxins affecting the pregnant sow have also been implicated.

The pig is then born into an environment where it struggles to keep its legs together, the muscles are strained and damaged making it difficult and/or painful to contract them and hold the legs together. This damage will occur as a result of the normal ‘scrabbling’ for a teat.

Prevention

Where splayleg is recognised as a significant condition within a herd, it is necessary to review, with your veterinary surgeon, all the factors which may be contributing to the problem. This will include breeding policy, housing and husbandry of the pregnant sow, nutritional management and a review of flooring in the farrowing area. The provision of copious bedding around the farrowing period may help to reduce the incidence of the condition. Shredded paper may be useful on fully slatted floors. Alternatively, latticed rubber matting (sold as safety matting for swimming pools) can be used behind the sow during farrowing.

Treatment

Survival of front leg splays and ‘stars’ is very poor and, in general, early euthanasia may be the best option.

For hind leg splays, recovery can be excellent if time and care are provided. In the first few hours, the piglet may require assistance to suck to ensure a reasonable intake of colostrum. Assisted sucking alternating with boxing away, under a heat lamp for the first 24 to 48 hours, can reduce overlaying losses in compromised pigs. The traditional method of treating such pigs involves tying the back legs loosely together below the hocks. Insulating tape works reasonably but must be removed before it cuts in to the skin. Specially made hobbles using Vicryl are also available and are re-useable; string and baler twine are not acceptable.

Considering that it is the upper muscle masses of the leg, which control the hip joints, which are compromised, better results may be achieved by taping the hips together. Again, insulating tape works well and should pass over the back in front of the pelvis, down either side to cover the leg below the hip joint to meet at the back below the tail underneath the anus/vulva. Again, do not leave the tape on too long (three to five days should be plenty); do not make it too tight and do not block the anus/vulva. (Figure 5.)

The most labour-intensive but more effective treatment is massage. Vigorous working of the muscles of the upper leg and rump using thumb and forefinger for five minutes every few hours in the first day or two of life can give an extremely good recovery rate. If undertaken, the legs should not be taped as the idea is to encourage muscle development and this will not occur if the muscles are not working.

Costs

No specific costings are available for splayleg on a national basis and the costs involved on an affected farm will depend on the extent of the problem.

Costs are incurred:

  1. as a result of additional labour needed to nurse affected pigs.
  2. mortality associated with affected pigs. With a weaned pig worth in the order of £40 (at 2010 prices) a one per cent mortality due to splayleg in a 600-sow breeding herd will cost nearly £6,000 per year.
December 2010
